Technical Specification
| Size : | PG 7 to PG 48 and M12 to M63
|
| Standard : | EN 60259,EN 50262:1999
|
| Application : | Suitable for everyplace where IP68 protection is required against dust,liquid,water,strain,twist and vibration. IP68 cable glands are mostly used in measuring and controlling instruments,machineries and equipment.Provied shake and twist proof protection.
|
| Function: | Metric,PG
|
| Ingress : | Maximum strain relief through clamping range. Trapezoidal thread with high torque guarantee.
|
| Thread: | IP68- 15 bar
|
| Operating Temp: |
-20°C to +100°C
|
| Material: |
Nickel Plated Brass
|
| Insert: |
Polymide PA6
|
| Accessories:
|
Lock Nut,Neoprene washer,Polyamide insert and Perbunan O Ring
|
| Gland Size |
Thread "C" |
Thread Length"D" |
Cable Range Dia. |
(A/F) | (A/C) | CAT NO. |
|
| Min. "A" |
Max. "B" |
||||||
| PG-7
|
PG-7
|
5.00
|
3.00
|
6.50
|
14.00
|
15.55
|
CIP68-7
|
| PG-9
|
PG-9
|
6.00
|
4.00
|
9.00
|
17.00
|
19.00
|
CIP68-9
|
| PG-11
|
PG-11
|
6.00
|
6.00
|
11.50
|
20.00
|
22.00
|
CIP68-11
|
| PG-13.5
|
PG-13.5
|
6.00
|
7.00
|
13.00
|
22.00
|
24.00
|
CIP68-13
|
| PG-16
|
PG-16
|
6.50
|
8.00
|
15.00
|
24.00
|
26.60
|
CIP68-16
|
| PG-21
|
PG-21
|
7.00
|
11.00
|
19.00
|
30.00
|
33.00
|
CIP68-21
|
| PG-29
|
PG-29
|
8.00
|
16.00
|
26.00
|
40.00
|
44.00
|
CIP68-29
|
| PG-36
|
PG-36
|
9.00
|
22.00
|
34.00
|
50.00
|
55.50
|
CIP68-36
|
| PG-42
|
PG-42
|
10.00
|
27.00
|
38.00
|
58.00
|
55.50
|
CIP68-42
|
| PG-48
|
PG-48
|
10.00
|
35.00
|
44.00
|
64.00
|
70.00
|
CIP68-48
|
Tolerance + 1mm
| Gland Size |
Thread "C" |
Thread Length"D" |
Cable Range Dia. |
(A/F) | (A/C) | CAT NO. |
|
| Min. "A" |
Max. "B" |
||||||
| M 12
|
M 12
|
5.00
|
2.50
|
6.50
|
14.00
|
15.50
|
CIP68-12
|
| M 16
|
M 16
|
5.00
|
4.00
|
8.50
|
17.00
|
19.00
|
CIP68M-16
|
| M 20
|
M 20
|
6.00
|
7.00
|
13.00
|
22.00
|
24.00
|
CIP68-20
|
| M 25
|
M 25
|
7.00
|
8.00
|
16.00
|
27.00
|
30.00
|
CIP68-25
|
| M 32
|
M 32
|
8.00
|
11.00
|
21.00
|
34.00
|
36.00
|
CIP68-32
|
| M 50
|
M 40
|
8.00
|
15.00
|
27.00
|
42.00
|
46.00
|
CIP68-40
|
| M 40
|
M 50
|
9.00
|
22.00
|
35.00
|
55.00
|
60.00
|
CIP68-50
|
| M 63
|
M 63
|
10.00
|
35.00
|
48.00
|
65.00
|
70.00
|
CIP68-63
|
Tolerance + 1mm
Tolerance ± 1mm
